HMC1075 orizontal CNC fraisage machin
- Gwosè Worktable: 1360 * 600mm
- Worktable max. chaj: 800Kg
- Ranje vwayaj nan X / Y / Z aks: 1000 * 750 * 600mm
- Taiwan BT50 file koton ak 24pcs disk kalite zouti magazin.
Dekri teren
Karakteristik teknik
Karakteristik prensipal HMC1075 orizontal CNC fraisage machin
- Rezin sab jete: HCNC-Group orizontal CNC moulen fèt ak jete sab résine HT300 ak yon estrikti ki gen fòm P, ki se mete ki reziste ak chòk ki reziste.
- Spindle: adopte Taiwan spindle ak vitès jiska 8000r pou chak minit.
- Zouti magazin: vitès chanjman zouti ki estab ak vit. 24pcs magazin zouti disk.
- Gid ak vis: meyè kalite C3 boul gid rails ak presizyon BEARINGS yo ekipe pou sa a orizontal fraisage cnc machin, asire vitès pwosesis segondè li yo ak friksyon ki ba.
- Konpozan mak: konpozan entèn tankou konpozan elektrik, konpozan pneumatic ak elatriye se nan mak entèn pi popilè tankou SMC, WAGO, NSK, SKF, ak sou sa.
- Entelijan HMC machin: sipòte IOT ke pwogrè pwosesis la, estati sante machin, echèk, elatriye yo tout anba kontwòl ou ak sèvis iNC-Cloud nenpòt lè ak nenpòt kote.
- Founisè ki gen konfyans epi ki kapab: ekip teknik pwofesyonèl, plis pase 100+ patant teknik.
Paramèt teknik nan machin CNC orizontal
HMC1075 fraisage machin teknik paramèt | |||||
Atik | Spec | Inite | |||
Tablo travay | Gwosè worktable | 1360×600 | mm | ||
Worktable max. chaj | 800 | kg | |||
T-slot dimansyon | 5-18-100 | Mm/moso | |||
Vwayaje | Vwayaj aks X | 1000 | mm | ||
Vwayaj aks Y | 750 | mm | |||
Z-aks vwayaj | 600 | mm | |||
Distans soti nan fen file koton ak tab travay la | Max. | 900 | mm | ||
Min. | 150 | mm | |||
Distans ant sant file koton ak sifas gid Z-aks | 590 | mm | |||
Spindle | Cône axe (7:24) | BT 50 φ155 | |||
Vitès | 8000 | r/min | |||
Pouvwa motè koton | 7.5 | kw | |||
Manje | Traverse rapid | X-aks | 12 | m/min | |
Y-aks | 12 | ||||
Z-aks | 24 | ||||
Feedrate | 1-10000 | mm/min | |||
Magazin | Kalite magazin | Kalite disk | |||
Kapasite magazin | 24 | moso | |||
Tan chanjman zouti | 2.5 | s | |||
Pozisyon presizyon | Estanda deteksyon presizyon | JISB6336-4: 2000/GB/T18400.4-2010 | |||
X/Y/Z-aks | ±0.008 | mm | |||
X/Y/Z-aks repete pwezante presizyon | ±0.005 | mm | |||
Gwosè an jeneral | 2600×2380×2400 | mm | |||
Pwa machin | 8000 | kg | |||
Konfigirasyon prensipal yo nanHMC1075orizontal D'
HMC1075 cnc fraisage | ||
3-aks kote yo pote | Anndan dyamèt 30, deyò dyamèt62, P4 | TPI/NACHI |
3-aks boul vis plon | X/Z: FD4012, Y: FD5010 | HIWIN/PMI |
3-Gid aks | X: HGH55HA, Y: HGH45HA | HIWIN/PMI |
Zouti magazin | Kalite disk, 24T BT50 | Okada/Desu |
Axe senti | BT50-155-8000r/min | Danquan/Haozhi |
Air silenn | 4.5T | Haodeng |
3-kouvèt teleskopik aks | Plak asye | Zhongjie |
Aparèy chanm konpwesyon lè | AirTAC | |
Ponp lubrifyan | TZ-2202-110A | HERG/Shengxiang |
Ponp awozaj | CBK4-30/3 | Rocoi |
Echanjeur chalè | HPW-10AF | Tongfei/Winhee |
Ka aplikasyon siksè nan fraisage orizontal la
